Product Details

CPH-MN635NP Audio Jack Mono 6.3mm

0.6868  - 0.7995  Excl. Tax

Product: CPH-MN635NP
Connection Type:
Description: CPH-MN635NP Audio Jack Plug
Audio Jack Type: Mono
Wiring: Solder Contacts

275 in stock (can be backordered)

Quantity Discount (%) Price
25 0.7995
50 6.4 % 0.7483
100 8.97 % 0.7278
200+ 14.1 % 0.6868
Compare
SKU: 5016 Category: Tags: , , ,

Share this product

Description

Technical Information

Product
Title CPH-MN635NP
Connection Type Audio Jack Mono
Gender Male
Electrical
Rated voltage 12Vdc
Input Current 1 A
Contact resistance 50mΩ
Voltage Withstand 500Vac (For 1 Min.)
Insulation resistance 100MΩ (@ 500Vdc)
Mechanical
Cable O.D. 3.5 – 8.0 mm
Insertion force 4 Kgf
Withdrawal force 4 Kgf
Lifetime 5000 cycles
Audio Cable Input Size ≤ 8mm
Wire size 24 – 22 AWG
Wiring Solder contacts
Soldering 400°C (Typ. for 1 sec)
description
material / Plating (Color)
Tip Brass / Nickel
Insulator ABS (UL94HB) / Black
Sleeve Brass / Nickel
Crimp Contact Brass / Nickel
Cover Brass / Black
Plastic Tube PE / Natural
Environmental
Flammability UL94-ΗΒ
Standard compliance IEC 61076-2-103
Solderability Complies with IEC 68-2-20
Temperature range -25°C to +70°C

MECHANICAL DRAWING

CPH-MN635NP Audio Jack Stereo 6.3mm Drawing

CPH-MN635NP Drawing

Additional information

Weight 35 g
Dimensions 66.5 × 11.5 × 11.5 mm
Gender Type

Male

Rated Voltage

Wiring

Solder
